Product features

Real time monitoring of the damage status of the protective net using resistance detection technology;

Built in GPS positioning device for real-time positioning equipment;

Anti disassembly detection, capable of real-time monitoring of equipment status, and real-time alarm when the equipment is dismantled or moved;

Two channels of protective net damage monitoring, two channels of door magnetic monitoring, and one channel of active human intrusion detection;

Built in lithium battery, integrated solar charging panel can work for a long time;

Built in 4G communication; Wireless real-time communication, timed start;

The linked area camera can capture when it is damaged.

Equipped with professional disassembly electronic keys; Reusable; technical parameter

Operational principle

1. During normal operation, the power indicator light flashes and is in real-time monitoring mode.

2. When there is one or more alarms, the sound and light alarm will be activated, and the alarm status will be locked, immediately initiating data upload.

3. When the data upload is completed and the alarm status has not changed, an alarm will sound for 4 seconds after a 1-minute interval.

4. When the alarm status changes to normal monitoring status, the sound and light alarm stops and data upload starts.

Project	Parameter
On/off detection channel	2-way
Magnetic lock monitoring channel	2-way
Anti rollover channel	0-15 meters
Human infrared intrusion	1 channel
Detection distance	0.5 meters
Detection angle	± 5 degrees
Response time	1s
Alarm method	acousto-optic
Functional module	Anti disassembly, electronic key
Communication methods	Built in 4G communication
Power supply method	Battery+solar energy
